StrongBox - Heavy Duty Wall Mount Enclosure (Weather and Vandal Resistant)

SHARE
This front-entry enclosure by StrongBox is designed for high durability and resistance to weather and vandalism, crafted entirely from stainless steel. The louvered main housing ensures cross-flow ventilation while deflecting water spray, insects, and dust through filter screens. It includes a removable stainless steel backboard secured by four bolts for mounting various equipment. The door features hemmed edges to eliminate sharp edges, a continuous piano hinge, and a three-point locking mechanism compatible with padlocks. A continuous drainage channel around the door provides a watertight seal with a thermoplastic door gasket. For installation, the enclosure includes stainless steel wall mount hangers and a pre-punched bottom plate for electrical conduit connections. Conveniently, the inside door accommodates instruction or plan storage. This enclosure meets NEMA 3R and UL 508A standards, addressing both environmental and safety requirements. StrongBox is ISO 9001:2015 certified, ensuring stringent quality management practices.
Most popular related searches
wall mounted enclosure
drainage channel
gasket sealing
safety regulations
channel drainage
screen filter
cross-flow filter
gaskets
dust filter
dust control

THE ULTIMATE WALL MOUNT ENCLOSURE WEATHER RESISTANT – VANDAL RESISTANT

  • 100% stainless steel construction assures long-term, rust-proof durability and additional strength
  • Wall mount brackets provide strength and security, while bottom plate includes conduit holes
  • Three point locking mechanism, flush mounted access handle and heavy duty continuous hinge ensures maximum security
  • Removable, predrilled backboard and trays provide for easy installation of controllers
  • Chameleon effect of the natural brushed stainless steel finish provides an unobtrusive quality
  • Filtered side louvers at bottom and top allow passive cross flow ventilation
  • Mounting template, stainless steel anchors and instructions
  • NEMA TYPE 3R rated UL  508A Listed
  • Powder coat colors available at additional charge
  • Ten year limited warranty

This front entry enclosure is a vandal and weather resistant enclosure formed entirely of stainless steel. The main housing is louvered to allow for cross flow ventilation and filter screens deflect against water spray, insects and dust. A removable stainless steel backboard is provided for mounting various types of equipment and is secured with four stainless steel bolts.

The door is hemmed to eliminate sharp edges and secured with a stainless steel, continuous piano hinge, and a three point locking mechanism with provisions for a padlock. A continuous drainage channel around all sides of door face provides a water-tight seal with the tear drop shaped, hollow center, thermoplastic door seal. Stainless Steel wall mount hanger brackets and pre-punched bottom plate are provided for easy installation and connection of electrical conduit. The inside door also provides adequate storage for instructions or plans. This enclosure is NEMA 3R rated and UL 508A listed.

  • Our Controller Subassembly includes 120 volt, 15 amp, ground fault protected duplex box with receptacle & locking switch: flexible conduit & condulet; & terminal strips with placards
  • The Thermostatically Controlled Fan is easily installed & can be adjusted in the field to help maintain desired enclosure temperature
  • The Rain Switch Enclosure is designed to protect WCS & Mini-Click Rain Switches from vandalism
  • The Pole Mount Rain Switch Enclosure mounts to 2” galvanized pipe
  • Solar Sync Cover is designed to protect Solar Sync switches from vandalism & made to attach to Strong Box enclosures with gasket seal
