StrongBox - Weather Resistant Light Duty Cabinet
FromStrongBox
The Weather Resistant Light Duty Cabinet by StrongBox is engineered for durability and reliability in outdoor settings. It is constructed entirely from stainless steel, providing long-term rustproof durability and enhanced structural integrity. The cabinet features a flush-mounted removable door equipped with a keyed cam lock for security. A natural brushed stainless steel finish offers a subdued and unobtrusive appearance. Ventilation is facilitated through filtered side louvers at the bottom and top, ensuring passive cross-flow ventilation. Inside, a removable backboard allows for easy component installation and is secured with stainless steel bolts. The cabinet door employs a continuous piano hinge and cam-style lock, with a drainage channel ensuring a water-tight seal via a thermoplastic door gasket. Installation is straightforward with stainless steel wall mount hanger brackets and a pre-punched bottom plate for electrical conduit connections. Rated NEMA 3R and UL 508A listed, this cabinet is also available with powder coat colors for an additional charge and comes with a ten-year limited warranty.Most popular related searches
gasket sealing
structural integrity
drainage channel
gaskets
temperature switch
channel drainage
drainage water
- Our Controller Subassembly includes 120 volt, 15 amp, ground fault protected duplex box with receptacle & locking switch: flexible conduit & condulet; & terminal strips with placards
- The Thermostatically Controlled Fan is easily installed & can be adjusted in the field to help maintain desired enclosure temperature
- The Rain Switch Enclosure is designed to protect WCS & Mini-Click Rain Switches from vandalism
- The Pole Mount Rain Switch Enclosure mounts to 2” galvanized pipe
- Solar Sync Cover is designed to protect Solar Sync switches from vandalism & made to attach to Strong Box enclosures with gasket seal
THE WEATHER RESISTANT CABINET
- 100% stainless steel construction assures long-term, rustproof durability and additional strength
- Flush mounted removable door with keyed camlock,
- Chameleon effect of the natural brushed stainless steel finish provides an unobtrusive quality
- Filtered side louvers at bottom and top allow passive cross flow ventilation
- Removeable backboard for easy component installation
- Mounting template, stainless steel anchors and instructions included
- NEMA TYPE 3R rated UL 508A Listed
- Powder coat colors available at an additional charge
- Ten year limited warranty
- Our Controller Subassembly includes 120 volt, 15 amp, ground fault protected duplex box with receptacle & locking switch: flexible conduit & condulet; & terminal strips with placards
- The Thermostatically Controlled Fan is easily installed & can be adjusted in the field to help maintain desired enclosure temperature
- The Rain Switch Enclosure is designed to protect WCS & Mini-Click Rain Switches from vandalism
- The Pole Mount Rain Switch Enclosure mounts to 2” galvanized pipe
- Solar Sync Cover is designed to protect Solar Sync switches from vandalism & made to attach to Strong Box enclosures with gasket seal
