Potential - Model PE - SPDAS -Submersible Positive Displacement Archimedes Screw Pump
PE - SPDAS pumps are multipurpose submersible Archimedes screw pumps with a pumping capacity of 20 to 110 m3/hr. Pumps are designed for use in skimmers and offloading applications. This hydraulic driven positive displacement pump with low screw speed avoids further emulsification of the recovered product thus making further separation more efficient. Pump can handle solids up to 30 mm in diameter. Stainless steel casings also enables the pump to be used in acid content liquids and other harsh environment. Well suited for many applications i.e. emergency pumping of heavy crude, bunker oil, bitumen, for tank cleaning, pipeline maintenance, sludge removal from waste oil pits.
PE-SPDAS pump has been specifically designed for a wide range of emergency and auxiliary pump operations. Pump handles liquids of an extremely high viscosity, like heavy crude oil or molasses, as well as low viscosity liquids such as diesel fuel or water; and it will cope with debris normally found in oil spill sites.
- Pump Discharge Size: 2" to 5" BSP
- Discharge Capacity: 20 - 110 m3/hr max.
- Pump Drive: Hydraulic Motor
- Screw MOC: Stainless Steel
- Casing MOC: Aluminium/Stainless Steel
- Shaft MOC: Stainless Steel
- Hydraulic Flow: 80 to 160 LPM
- Operating Hydraulic Pressure: 210 bar max
- Solid Handling Capacity: 30mm max
- Power Source: Hydraulic Powerpack
- Used where electrical power is hazardous or impractical
- Hydraulically operate
- Can be bolted directly to the tank
- Corrosion resistant
- Handles wide range of liquids from water to the heaviest debris laden viscous oils
- Equipped with an inlet side hot/cold water injection nozzle to deal with high and extreme viscosity oil
- Oily Water Treatment
- Oil Spill Response
- Oil & Gas
- Power
- Steel
- Wastewater & Water
- Sugar
- Dairy
