Sandvik - Model Ranger DX810i -Surface Top Hammer Drill Rig

SHARE

Ranger DX810i is a hydraulic, self-contained, crawler-based surface drilling rig. The rig features Sandvik intelligence options, powerful RD900 rock drills, reliable rock tools and an optimized drilling system with a drilling coverage of 290°.

Most popular related searches
surface drill rig
drilling rig
top hammer drill rig
rock drilling
drilling rock
rock drilling tool
drilling equipment
rock drilling rig
drilling tool
drill hammer

290° Revolving upper structure

Ranger™ DX910i revolving upper structure allows for a 290° reach and 55 m² drilling coverage, saving time by minimizing the need to reposition your rig.

Spacious iCab cabin

Operators experience an extremely low noise level of 73.5dB in the rig’s comfortable iCab cabin.

Range of rock drills

Benefit from the versatility provided by Ranger™ DX910i’s expanded rock drill selection (27 - 30kW). Leverage the drill rig across a number of applications thanks to the available rock drill options, including a new long-piston RD930C rock drill designed for efficient drilling of larger hole sizes.

With a unique curved thread, Sandvik CT55 and CT67 rock tools offer up to 20% higher penetration rates.

Find your match

Use our configurator
Opens in new window to quickly find the best combination of drill rig, rock drill and tools for your job site — just enter your rock type, hole size, and application.
