GHOPTO - Model GH-SW320-U2 & GH-SW320-Gnet -SWIR Camera
The SWIR Camera series feature a 640 x 512 pixel InGaAs focal plane array (FPA) with a pitch of 15μm. The camera operates in the 900nm – 1700nm wavelength range, which covers the SWIR region of the spectrum. The product has the characteristics of small size, high reliability and excellent environmental adaptability. The product adopts USB3.0 or CameraLink interface , and users can integrate it into the application system quickly and easily.
- Self-developed SWIR Camera
- Single point Correction
- TE Cooler
- Cost-effective
The camera is a high-performance SWIR camera that offers high sensitivity, low noise, and high resolution for imaging in low-light-level conditions. With its advanced features and capabilities, this camera is an ideal choice for various applications such as surveillance, astronomy, machine vision, industrial process monitoring, and medical imaging.
- Sensor: GH-SW320
- Resolution: 320 x 256
- Spectral Response: 0.9pm - 1.7pm
- Pixel Pitch: 1 5pm
- Lens mount: C - Mount
- Quantum Efficiency: >70% (1.0pm - 1.6pm}
- integration Type: 2.2 Me-
- ADC: 14b it
- Cooling: TEC
- Dark Current: 30fA@0.1V&18°C
- Software: Windows Software/windows SDK
- Trigger: RS-422 / TTL
- Exposure Mode: Global exposure
- Readout mode: IWR
- Power Input: DC12V±2V
- Power consumption: <4W(TECoff)
- Weight: 200g (No lens)
- Dimensions: 55mm x 50mm x 63mm (No lens)
- Operating Temp: -20°C~+50oC/-40oC~ + 70°C (Optional)
- Storage Temp: -40 °C ~ + 80 °C
- On-board Image Processing: Single/two-point correction, bad pixel replacement, image denoising. image smoothing, controllable shutter compensation
