Synova - Model DCS 50 -Diamond Cutting System
The DCS 50 is Synova’s most compact diamond machining system. The 3-axis machine is designed for cutting pointers (0.1 to 1.5 cts.). The DCS 50 with two additional rotary axes also allows high-precision coning, blocking and fancy shaping.
The machine uses linear motor driven X-, Y- and Z-axes (DCS 50-3) with additional B and C rotary axes enabling accurate diamond machining such as blocking and shaping (DCS 50-5).
The state-of-the-art CNC machine system offers a high-power green laser, a compact high-pressure water pump with an ultra-pure water unit, a touch-screen control panel and a vision system with motorized zoom.
Materials:
- Rough diamonds
- Laboratory grown diamonds (CVD, HPHT)
Operations:
3-axis machine: Sawing, slicing
5-axis machine: Sawing, pie sawing, slicing, drilling, fancy and round bruting, coning, blocking/ faceting
- Easy
- No focus control necessary due to long working distance
- No blackening, no opening, no double sawing needed
- Very little post treatment required
- Profitable
- Minimal weight loss and low risk of breakage
- Fast cutting time and easy processing
- Diamond sawing in mass production
- Straight and Smooth
- Smooth cutting surfaces and sharp edges
- Cylindrical beam resulting in perfectly parallel kerfs (no V-shape)
- Virtually no heat impact thanks to the water jet cooling capability
