Tablebox - Model Air -Mobile Filter Device
As a mobile filter device for extracting welding fumes as well as free-flowing and dry dust, the AirBox® enables users to deploy it flexibly at different workplaces in production. The extraction arm with a rotating and swivelling extraction hood offers a very high level of flexibility for at-source collection. The AirBox®`s integrated pre-separation system sorts out coarse particles in advance, thus ensuring a long service life for the main filter. The filter cartridge is equipped with high quality filter material of dust class "M". Its separation efficiency is 99.9 %. The cartridge can be changed easily and conveniently. The AirBox® will also soon be available with the IFA test mark “W3” for extracting welding fumes when machining chrome-nickel steel.
Most popular related searches
mobile filter system
welding fume
filter cartridge
activated carbon
extraction arm
extraction hood
welding fume extraction
cartridge filter
dust filter
fume extraction
- Mobile use and suitable for continuous operation
- Compact and easy-to-handle design
- A drawer enables simple and dust-free disposal of the collected material
- Filter cartridge with dust class M
- Quiet and energy-saving operation thanks to EC technology
- Stepless adjustment of the air volume flow
- Operating hours counter
- Single-place extraction in industry and trade
- Suitable for welding fumes, free-flowing and dry dust
- Max. airflow volumem³/h 950
- Connection voltageV 230
- Nominal frequencykW 0.51
- Filter aream² 13.57
- Number of filter elementsunits 3
- Activated carbon volumel -
- Number of activated carbon catridgesunits -
- Dimensions (L/W/H)mm 692 ×660 ×959
- Weightkg approx. 100
- Sound pressure leveldB(A) 60.5***** (68.5)
