Tecme - Model HP Series -Stainless Steel Sterilizer
HP Sterilizers use a reactor made of stainless steel AISI 316 that houses a `high power` and `medium pressure” mercury vapor lamp. The use of electronic “ballast” allows a pre-heating phase and an accurate control of the power supply frequency in order to avoid the `flicker` effect by optimizing the system performance and extending lamp life.
The sensors
All models have a sensor calibrated according to DVGW (DeutscheVereinigungdes Gas und Wasserfaches) for the control of uvc dose inside the reactor and a water temperature sensor inside the chamber which allows to set different alarm thresholds.
Electronic control
All our uvc systems have an electronic control with large backlit alphanumeric display on which the user can check, at any time, the efficiency of the machine, the parameters set and eventual alarms. A bus connection enables the use with other systems in the field.
The cleaning system
HP sterilizer has a quartz tube automatic cleaning system driven by an electric motor.
