TekMark - Down the Hole Casing Puller

The down the hole casing puller is specifically designed to install PVC liner and to retrieve dropped PVC casing/This tool works off a drill string or drop pipe and a 1/8" cable. When you pull on the drill string or drop pipe the lower section wedges the top section and exerts outward pressure on the PVC, steel or iron pipe. If you wish to extract the tool you pull up on the cable (which is attached to the top section of the tool) while pushing down slightly on the drop pipe or drill string and the tool will be released so you can lift it to the surface. This tool can be used to set liner down hole. The down hole casing puller can be shimmed to work on several casing IDs. Ask for a quote for the addition of shims. Capacity: 20,000 lbs.
