TekMark - Heavy Duty Column Pipe Holders
The TekMark Heavy Column Pipe Holder is used to lift and install column pipe. There are 4 of these 3/4" carbide pads gripping the pipe, 2 on each slip.
Most popular related searches
- Shipping Weight: 75 lbs.
- 24" x 8" x 8" to top of linkage. Handle is removable and can be used on either end of holder.
- Capacity: 20,000 lbs. lifts off O.D. pipe wall.
- Slip sizes include 1", 1.25", 1.5", 2", 2.5", 3" 3.5" and 4" column pipe and A, B, N drill rod.
- Holds galvanized or plain steel pipe, stainless steel pipe and either flush joint or coupled PVC
- Optional wire guide shown in picture above on left. With wire guide the holder is wider allowing space between slips and holder frame with a "Roller" guide mounted on holder frame wall. This guides the wire automatically as column pipe is installed or extracted.
