Ankersmid - Model ATC 506/508 -Temperature Controller for Wall-mounting
The electronic temperature controller is mounted in a wall-mounting housing. The temperature sensor input is developed for multiple sensor inputs (standard PT100). The desired operating temperature can be set by using the respective control keys. The actual value is indicated via 4-digit display and the controller > function via LED.
Most popular related searches
The ATC 506/508 is a modern microprocessor-based (PID) control device. The innovative design facilitates an easy operation. The plug-in device, which is equipped with a grounding-type plug and a multi-pole plug for the consumer unit, can be put into operation immediately.
- Compact design
- Relay contact 16A switching capacity
- Multi-colour LED indication
- Plug-in device
- Grounding-type plug for mains connection
- 7-pin Multipole plug output
- Quick and easy to operate
