- 4 Layers Depth Filter

From

0

New depth filter in 4 layers of filtration. The TWINPURE is made with four different pore diameters as the corresponding patent MULTI-LAYER. The filter element has 4 layers of polypropylene fiber structure, depth and high vacuum volume. It works with fine pores micronage in the inner layers and thicker micronage over its outer layers. They consist of 4 different pore diameters in each of its layers to ensure a selective filtering. The item get a longer service life and optimized filtering in each of its layers of filtering. New filter into 4 layers deep.

  • High level retention of selective pollutant.
  • High durability in service
  • Large volume empty in the structure of the media.
  • Four different microns in the same filter element.

  •  100% Polypropylene
  • Offers compatibility with a wide range of fluids in different processes
  • Free of adhesives
  • Manufactured according to standards NSF40 / FDA, CFR
  • Free media migration
  • Micro fusion Polypropylene fiber
  • Heat sealed filter structure
  • High density in the fibers give very rigid support without internal tube
  • Resistant to pressure differential of 3.2 Kg/cm2
  • Free of epoxy in the manufacturing
  • Terminations thermo welded cartridge
  • Filtration reliable and reproducible results

Maximum working pressure:

  • At a temperature of 60 º C 1.8 Kg/cm2
  • At a temperature of 20 º C 3.2 Kg / cm2
  • We recommend replacing the filter element to a (differential pressure 1.5 Kg / cm2
  • Maximum working temperature 60 º C

  Microns pore size

  • 0.5 microns – 1 micron – 3 microns – 5 microns
    10 microns – 25 microns – 50 microns – 75 microns – 100 microns

Length in Inches

  • 9.87 “- 10” – 20 “- 30” – 40 “- 50”

Presentations

  • 10 “boxes of 50 units
  • 20 “25-pack boxes
  • 30 “boxes of 20 units
  • 40 “boxes of 20 units
  • 50 “boxes of 20 units

Diameters

  • Internal 28 mm
  • External 63 mm

  • Seawater desalination and brackish
  • Water for Aquaculture (Hatchery, Nursery)
  • Process Water
  • Pre-filtration of UV, DI and RO
  • Filtration of low viscosity Chemical Products
  • Oil absorption of low pressure
  • Filtration of inks and photographic emulsions
  • Filtration of paints and resins
