Zhuhai Wangyang - Model WY-UF-10 - 500LPH -Ultrafiltration UF Systems
Ultrafiltration technology is a kind of membrane filtration method. It uses asymmetric microporous structure and semi-permeable membrane medium at a certain pressure and flow rate at room temperature, and relies on the pressure difference between the two sides of the membrane as the driving force to filter in a cross-flow manner. Solvents and small molecular substances pass, and macromolecular substances and fine particles such as proteins, water-soluble polymers, bacteria, etc. are retained by the filter membrane to achieve separation, classification, purification, and concentration. A new type of membrane separation technology.
Most popular related searches
ultrafiltration system
ultrafiltration
membrane separation technology
membrane separation
filter membrane
membrane filtration
water microbiology
filtration membrane
UF technology
- Model: WY-UF-10
- Water yield: 500 litres/hr
- Recovery rate: 90%
- Inlet water temperature: 5~45℃
- Product water turbidity: <0.1NTU
- SDI: <1
- Power: AC380V / 50Hz / Three phase
- Inlet water pressure: 0.1-0.4Mpa
- Total inlet flow: 560 litres/hr
- Power: 0.55KW
* 1. Equipment can be customized according to customer requirements.
