NeoTech RefleX - Model D238 -UV Disinfection Chambers for Ultrapure Water Applications
The RefleX D238 UV Disinfection Chambers are specially designed for the ultrapure water industry, offering a notable contribution to advanced oxidation and water purification processes. Utilizing an innovative patented technology, these chambers achieve a remarkable reflection rate of 99.8% of 254 nm UV light, significantly enhancing the system's efficiency. The compact design features a 75% smaller footprint than conventional UV systems, incorporating 38-inch high-output lamps to deliver superior performance while minimizing costs. It is designed for ease of maintenance with no-tool lamp changes and is equipped to be mounted either vertically or horizontally. The chamber is certified by NSF 50 and NSF 61 standards and boasts up to 75% reduced energy consumption. It also includes RefleX Controllers for independent operational management of up to four chambers, with real-time dosimetry and TUV safety certification. Operating at a flow rate of 150 gpm, the system maintains a 95% UV transmittance at 30mJ/cm², marking it as an efficient choice for demanding applications. The NeoTech D238's design ensures unmatched UV distribution while reducing lamp and power requirements by up to 90% compared to standard systems.
RefleX D238 UV Disinfection Chambers
An essential component in advanced oxidation processes and water disinfection, RefleX UV Chambers use patented technology to reflect 99.8% of 254 nm UV generated back into the chamber flow
With a 75% smaller footprint than standard UV systems and 38” high-output lamps, RefleX D238 UV Chambers provide highly efficient performance with the lowest cost service schedule of any low or medium pressure UV system available
Take command of more in less space
RefleX Controllers provide the information you need at a glance – with the ability to control up to four treatment chambers independently from a simple menu.
RefleX D238 UV Disinfection Chambers
An essential component in advanced oxidation processes and water disinfection, RefleX UV Chambers use patented technology to reflect 99.8% of 254 nm UV generated back into the chamber flow
With a 75% smaller footprint than standard UV systems and 38” high-output lamps, RefleX D238 UV Chambers provide highly efficient performance with the lowest cost service schedule of any low or medium pressure UV system available
Take command of more in less space
RefleX Controllers provide the information you need at a glance – with the ability to control up to four treatment chambers independently from a simple menu.
- Control up to four chambers from a tidy 8X9X4” footprint.
- Flow Rate: 150 (34) gpm (m3/hr.), 95% UVT @ 30mJ/cm2
- Lamps: One high-output amalgam lamp
- Power: 240 watts with control box
Maximum UV Penetration
The NeoTech D238™ provides users an unparalleled level of engineering sophistication by maximizing UV distribution in a patented 99% reflective chamber
This unique technical advantage also reduces the number of lamps and power requirements by up to 90% compared to standard UV systems.
Minimal Maintenance
The service and maintenance for RefleX UV Chambers have three basic requirements:
- Lamp Replacement: No tools needed
- UV Monitor: Changed out with screwdriver during operation
- Cleaning: May be cleaned as needed in a CIP loop or manually brushed.
Maximum UV Penetration
The NeoTech D238™ provides users an unparalleled level of engineering sophistication by maximizing UV distribution in a patented 99% reflective chamber
This unique technical advantage also reduces the number of lamps and power requirements by up to 90% compared to standard UV systems.
Minimal Maintenance
- The service and maintenance for RefleX UV Chambers have three basic requirements:
- Lamp Replacement: No tools needed
- UV Monitor: Changed out with screwdriver during operation
- Cleaning: May be cleaned as needed in a CIP loop or manually brushed.
Unparalleled Efficiency.
The NeoTech D238™ boasts the smallest footprint in its class. With as few as one-tenth as many bulbs compared to standard UV systems, it has the lowest operating cost and maintenance schedule in the field.
Higher reflectivity for higher transmissivity.
The UV transmissivity (UVT) of the treated water, combined with the flow rate through the unit, determine the UV dosage applied to the water. Particles in water typically absorb or reflect UV light which affects the water's UV transmissivity. NeoTech Aqua’s units are rated based on a UVT of 95%. The above graph illustrates the appropriate rating for the D238 based on varying UVT levels. The NeoTech Aqua Solutions technical team provides complimentary UVT analysis on customer-supplied water samples to ensure proper UV equipment sizing.
