EBRO ARMATUREN - Valve for tank trucks type TW 150/TW 200
Series production is our business - the development of customised solutions for special applications is our passion. For more than 40 years we have been developing tailor-made solutions in close collaboration with our customers, for challenging fields of application that simply require more than a standardised valve product. This has resulted in countless variations. Many of them have been developed to series production, others are manufactured in small batches for select applications. We can only show the tip of the iceberg here. Challenge us!Most popular related searches
Nominal diameter: DN 150, DN 200
Face-to-face: EBRO works standard
Flange connection: DIN 28459 flange for tank lorries
Flange surface design: DIN 28459 form A /B, ASME RF/FF
Tightness check: EN 12266 (leakage rate A), ISO 5208 category 3
Temperature range: -20°C to +160°C (depending on pressure and medium)
Max. operating pressure: max. 6 bar
Body: Aluminiumalloy GD-AlSi9Cu3 (3.2163)
Seat: EPDM, NBR, FPM,SBR-green
Disc: Stainless steel G-X6 CrNiMo 18-10 (1.4408), X5CrNi18-10 (1.4301)
CE marking number: 0036
TUEV number: 9001:2008
