Tri-Pak - Model TB7230 Series -Vertical Down Stroke Baler
The TB7230 Series from Tri-Pak is a robust vertical down stroke baler engineered for high-capacity recycling needs. This model is capable of producing bales up to 2,000 pounds, making it suitable for heavy-duty operations. It meets the latest ANSIZ245-2013 standards and complies with OSHA, CSA, UL, and MOL regulations regarding electrical and safety features. Key safety features include dual safety circuits and tamper-resistant coded magnet safety sensors. The baler uses a chain-free bale ejection system controlled from the front, utilizing its own cylinder to efficiently eject finished bales. The integrated PLC control panel enhances operational efficiency by notifying the operator with a `bale full` indicator light, thereby eliminating the need for manual checks. Optional upgrades such as rear wire guides, bale counters, and SCADA-based monitoring systems are available, allowing for reduced downtime and enhanced service diagnostics.
- UL/CSA Approved Design
- Meets/exceeds ANSI Z245.2 regulations
- Meets/exceeds OSHA regulations
- PLC “flex-design” based control systems
- NEMA 4 rated enclosure
- Internal timers prevent system run-on
- Self-diagnostic indicators
- 24-volt controls
- Adjustable multi-cycle timer
- 75% and 100% full light
- Auto-alert maintenance mode
- Heavy duty oil-tight pushbutton controls
- Key lockable start pushbutton
- Deep Chamber (42")
- Full bale light
- Hydraulic bale dump
- R.H. hinged bale door
- Barn style feed doors
- Rear wire guides
- Control System 110 volt 60 cycle powered by step-down transformer
- Control Panel Fully wired. Keyed start button, emergency stop, full lights, reset button
- Power 208/230/575 volt, 3 phase 60 cycle
Tri-Pak vertical balers are available in a wide range of sizes and capacities ranging from the TB-4527 series that produces a 100 pound bale to the TB-7230 series that can produce 2,000 pound bales. Every baler meets/exceeds the latest ANSIZ245-2013 specifications as well as the current OSHA, CSA, UL and MOL electrical and guarding regulations. Dual safety circuits are standard as are tamper resistant coded magnet safety sensors. Every baler is equipped with a chain free bale ejection system that is engaged from the front of the baler and uses the baler’s own cylinder to automatically eject the finished bale out of the bale chamber. The PLC based control panel alerts the operator via a “bale full” light when a full bale condition has been achieved. There is no longer any need for the operator to visually check to see how full the baling chamber is getting. Every baler can be upgrades with rear wire guides, bale counters, front door tie slots and a SCADA based baler monitoring system that is able to monitor all of the balers systems to reduce down time and gray area service calls.
