Wantai -Â Model 24-80V -Stepper Motor Driver
The quiescent current of the 24-80V Stepper Motor Driver can be set with the SW4 DIP switch. OFF means that the quiescent current is set to half of the dynamic current, and ON means that the quiescent current is the same as the dynamic current. In general use, SW4 should be set to ON, which can reduce the heating of the motor and driver and improve reliability. About 400ms after the pulse train stops, the left and right currents are automatically reduced to about half (60% of the actual value), and the calorific value is theoretically reduced to 30%.
Most popular related searches
Product details
- Name: 24-80V Stepper Motor Driver
- Speed setting (within 10~600) subdivision setting: 200~25600
- Current setting (within 0.7~5.2A)
- Can drive 4-wire, 6-wire and 8-wire motors
- With overvoltage, undervoltage, overcurrent, and phase-to-phase short circuit protection
Functions
- Signal input: single-ended pulse/direction
- Variable current control greatly reduces motor heating
- Photoelectric isolation, differential signal input
- With rising edge, falling edge, single and double pulse selection
- High response/high speed and low vibration, self-test function
