Wantai - Model 57HBM -Closed Loop Stepper Motor

57HBM Closed Loop Stepper Motor is a combination of stepper motor and closed-loop control. Because the open-loop control system of stepper motor has disadvantages such as low precision and lost steps, the closed-loop control system of stepper motor can be used in occasions with higher precision requirements. This control method is to directly or indirectly detect the position or speed of the transfer (or load), and then through feedback and appropriate processing, the drive pulse sequence of the stepper motor is automatically given. This drive pulse sequence is based on the load. Or the position of the rotor changes at any time. There are many realization methods of this control method. In the occasions that require high precision, the combination of micro-step drive technology and microcomputer control technology can achieve high position accuracy requirements.
