Dieselcraft - Model Magnum 60 -Waste Oil Centrifuge
The flow rate capacity of the oil centrifuge is 1 GPM or 60 gallons per hour. So one 55 gallon drum of oil will take less than 60 minutes to process once at operating temperature. The oil centrifuge at 80 PSI generates a centrifugal force of 3017 G?s Removing solids to less than 2 micron. No filters to buy. You can build a filtration system with this unit. The oil centrifuge will filter waste vegetable oil, Waste Motor Oil, hydraulic oil, and ATF that is heated to over 150 F. To make the system work you need this pump or equivalent: Standard Duty DAYTON Rotary Gear Pump: Carbonator, 1/3 hp HP, 115/230. Item #41TK24 Mfr. Model 41TK24.
Includes:
- 60 GPH centrifuge
- Control valve
- Four Hose clamps for 3/8 hose
- Centrifuge Only Kit Price $299
The Magnum 60 and Dieselcraft OC-50, 108 GPH Basic Waste Oil Centrifuge Filtration Units are the easiest and cost effective way to clean your waste oil.
The basic process:
- When building a filtration unit, you will need an open top 55 or 30 gallon steel drum, a centrifuge, a “gear pump” and motor and a drum heater.
- Begin by straining your oil to remove the larger particles.
- Heat your oil to 150 -180º F with the 1200 watt drum heater. Two heaters may be needed for winter operation.
- Pump the hot oil through the centrifuge for two to four hours. After a few hours you will have oil ready for blending.
- There are no filters or filter bags to replace – simply clean out the rotor in the centrifuge when it is full.
Used in the alternative fuels market for over 20 years with a 5 year warranty on all centrifuge parts.
Here is oil before and after the centrifuge process on the test paper. 99% of the solids have been removed from 50 gallons of oil. Simple!
