Aquatec Oval - Model AT 30 to AT 300 -Wastewater Treatment Plants
AT 30 to AT 300 oval wastewater treatment plants were invented to purify sewage water for blocks of houses, small village, parts of a village, accommodation properties, restaurants, recreational properties, manufacturing factories, industrial parks. After preliminary purification of industrial wastewater with organic pollution the plants serve as biological treatment for meat processing factories, dairy factories and slaughterhouse, wineries, etc. Furthermore the purified water can either discharge into the surface or to be utilized for irrigation.
Aquatec VFL oval wastewater treatment plant includes:
- Biological reactor of wastewater treatment unit.
- Air pump tank intergrated in the cover of the WWTP.
- Control unit AQC Basic with GSM remote control.
- Air pump or Air pumps regarding the type of the WWTP.
- 230V service plug.
The wastewater treatment systems comprised of the biological reactors from AT30 oval to AT250 oval can be gradually expanded by installing several units in parallel.
AT30 to AT250 oval wastewater treatment plants installation
- Are installed into the prepared hole as underground tanks on a concrete slab with a thickness of about 300 mm so that the top edge of the revision manholes overlaps about 50 mm above the terrain. Wastewater treatment plant is reinforced, without the need of putting concrete around.
- The backfill of the tanks is done with a sorted material of 4/8 mm fraction.
- The backfill should be done by layers, while creating a back pressure by filling the water into the tank.
