Atlas-Wedge - Model 304 316 T304 SS -Wedge Wire Cylinder

Cylinder Wedge Wire Filter Sieve for Bulgaria

Cylindrical welded wedge wire according to the sketch in below

• Commodity name: Cylindrical wedge wire filter sieve
• Dimensions: +/- 30 mm, Din 280mm, Din tolerance must be +/- 1 mm min.
• Length: 520mm
• Material - Stainless steel AISI304
• Projects: Bulgaria

Stainless steel 316 Wedgewire Cylinder

• For projects of out-to-in filtration, operating pressure 10 bar
• Material: SS316
• Size: 85 x 1000mm
• Filtration: 100 mesh
• Projects: Singapore

Stainless Steel T304 wedge wire cylinder
Of wedge wire screen with longitudinal slot opening 177, 210, 250 microns

• Outside diameter: (O.D.) = 160mm.
• Height: = 650mm
• Materials: SST304
• Opening slots: Longitidunal
• Welded rings and support rods: Yes
• Application: Beverage drinks. temp. 85 degree C. , pressure up to 6 barg.max.
• 177 microns flow rate 20m3/hr.
• 210 microns flow rate 20m3/hr.
• 250 microns flow rate 10m3/hr.

Wedgewire cylinders are mainly used in:

• Energy recovery filter elements
• Lauter tun screen used in breweries
• Sizing and separation
• Fluid dryer screen
• Washing screen

• Outside Diameter 1.375 inches
• Support rod 90
• V-Wire 69
• Slot Opening 0.007 inches
• # Support rod 16
• Material Stainless Steel 304 and 316

304 SS wedge wire 120CMI and 25x2 rods also in 304 SS,ID of cylinder 1,166m and length is 5,350m.
We can supply in off cut dimensions or in cylindrical form, wire and rods are supplied also.

0.700mm slot opening SS 304 Cylindrical WedgeWire

• 100mm x 900mmL x 0.700mm slot opening
• With standard flange on one end and closed on the opposite end
• Material: SS 304
• 30mm x 400mmL x 0.700mm slot opening
• With standard flange on one end and closed on the opposite end SS 304

Cylindrical sand control wedge wire pipe

• Wedge wire cylinders for the flow of water from inside the cylinder to outside
• 6 meter long, diameter 4, slot opening 1000, stainless steel 316.
• 3 meter long, diameter 1 slot opening 500, stainless steel 316.

Continuous slot wedge wire cylinders for sugar industries

• 1800 mm diameter x 4500 mm overall length slot size 0.50 mm
• 1800 mm diameter x 4500 mm overall length slot size 0.25 mm

The structure reinforced by externals 75mm x 10 mm joiner bars, 50 mm x 10 mm stiffeners and 75 mm x 10 mm ending ring both end. Including round bars for anti-torsion reinforcement.

The whole structure is made in two section all in AISI 304 SS material.
