GeoModeller - 3D Modelling Software

GeoModeller provides a variety of industry tools with a focus on value chain improvement for the mining, oil & gas, geotechnical, and groundwater industry.

Resource estimation, modelling, multi-scale data integration, advanced drillhole management, and reliability assessment modules are available for your in-house experts to extract the most relevant intelligence from your data. Industry users are offered a wide variety of licensing options, including site licenses, and premium online support.

Basic

GeoModeller Base V4.0

GEOLOGY MODELLING Full 3D geology model-building including all input/output, editing, visualisation, advanced drill hole management, interpolation of drill hole attributes, 2D/3D grid/mesh visualisation & computation, geology & resource volumetrics, property optimisation. Forward Grav-Mag geophysics modelling in 2.5D & 3D. And forward prediction of synthetic 2D seismographs.

Add-on GeoModeller Cluster Tool

For automated structural analysis: Performs 2D/3D point data clustering. Available for: conventional data (anisotropic, isotropic), tensor data, vector data. Dip calculation reports. Implicit surface solved for final planes (GM and INTREPID interoperable).

Intermediate

Add-on GeoModeller Grav/Mag Inversion

FULL GRAV/MAG INVERSION Litho-constrained stochastic geophysical inversion. Including joint inversion of any number and combination from: gravity, magnetics, tensor grids of Grav/Mag, and component tensor grids of Grav/Mag. Litho-constraints are either directly from 3D geology (GeoModeller-Base) or linked to an imported starting lithology or property voxet. Also includes any combination (%) from Fixed Geology Property-Only inversion to Fixed Property Geology Geometry-only inversion. This module also includes 3D geothermal computations, and a micro-seismic events record viewer with a temporal filter.

Add-on GeoModeller Geothermal

Forward heat flow modelling, integrated with the 3D geological modelling engine.

Add-on GeoModeller CGAL Libraries

For building meshes of surfaces and volumes by triangular and tetrahedral elements, derived from implicit models from GeoModeller, exporting to various finite element mesh formats.

Advanced

Add-on GeoModeller 1D Airborne EM Inversion & Support For Viewing 2.5D Inversion Products

Enabling: Load/interrogate your airborne EM survey data; Create geological sections for each line; Create a geology model and predict the 1D EM response; Review the predicted outcomes as log conductivity sections and 3D Point clouds of predicted resistivity/conductivity; Generate a request for a 2.5D inversion bureau service to be performed by Intrepid Geophysics for a fee (see below). Supports all common commercial airborne EM systems.

Add-on GeoModeller 2D/3D Worms

For automated structural analysis: Performs Multi-Scale Edge Detection (Worming) and Euler Depth to Basement. Creates databases CSV for worms, points, lines. Uses the Digital Terrain (GM and INTREPID inter-operable).

With its open science approach, academics are always assured of the exactitude of their results. GeoModeller is a transparent box with all its core functionalities fully described in leading edge publications and online documentation. Intrepid Geophysics is aware of the funding challenges researchers face and supports them with special academic pricing

GeoModeller is available as an educational tool for specialized teaching institutions via our student program. Registered students get the opportunity to be trained on industry grade software and practices for improved job prospects.

• Advanced Fault Network Management
• Drillhole Management
• Conceptualization for Groundwater modelling
• Geological Implicit Modelling
