Wastewater characteristics change continuously, depending on rainfall, industrial processes, and even the time of day. Over-aerating is a common, expensive problem that results in excessive energy costs and unnecessary wear and tear on your equipment.

This revolutionary aerobic wastewater treatment solution is modular and reduces energy usage by up to 90% compared to conventional treatment. Activated sludge treatment has long been used for aerobic wastewater treatment, but its aeration stage is particularly energy-intensive, which makes it less cost-efficient as a step in decentralized water reuse. At Fluence, our self-respiring membrane aerated biofilm reactors (MABR) provide an energy-efficient alternative. MABR is based on passive aeration, that is, the diffusion of oxygen through membranes.

Aspiral is a smart wastewater treatment solution that packages our innovative MABR technology in standard shipping containers. This modular solution reduces energy usage for aeration by up to 90% compared to conventional methods. Aspiral is an ideal solution for small- to medium-sized plants serving small towns, villages, residential communities, resorts, hotels, commercial complexes, and more. Aspiral`s efficiency makes it ideal for decentralized treatment off the grid since its low energy needs can be supplied by alternative sources.

Upgrade Wastewater Treatment Plants with SUBRE; With increased urbanization, wastewater resource recovery facilities face new challenges. When a conventional activated sludge wastewater treatment facility has reached its limit, Fluence`s SUBRE can come to the rescue. Instead of enlarging current plants and building new basins, SUBRE modules are submerged in existing chambers, improving effluent quality, lowering the use of chemicals, saving energy and operational costs, and enlarging capacity. SUBRE upgrades WWTPs using membrane aerated biofilm reactor (MABR) modules. SUBRE is designed to upgrade existing basins with capacities of 2,000-100,000 m3/d (0.5-25 MGD) or improve effluent qualities to meet stringent nutrient regulations.

With water scarcity threatening many parts of the world, more municipalities and private companies are exploring ways to treat and reuse wastewater to help secure their water supplies. Fluence’s containerized ECOBOX^™ water reuse system provides an affordable, plug-and-play solution that can be commissioned and start producing water less than seven days after the system arrives on-site. Ecobox is efficient and versatile. It can effectively treat greywater, and industrial and municipal wastewater streams for reuse anywhere in the world, at a competitive cost. And its compact footprint makes it ideal for small neighborhoods, green buildings, or commercial and industrial users in remote locations.

Fluence’s Tipton Series prefabricated, package wastewater treatment plants provide reliable, complete solutions for on-site treatment for municipal and private clients. With thousands of installations across the globe, Fluence has the expertise to build treatment plants to address a wide range of wastewater challenges. Tipton Series extended aeration packaged plants are designed for applications that require reliable, robust and cost-effective primary, secondary, and tertiary treatment solutions, all in a compact, portable, self-contained, and odor-free package, which can be shipped quickly to any customer, anywhere. Plants can be custom-configured for each project.

Our Aspiral containerized wastewater treatment solutions come in several configurations to treat from 20 to 350 m3/d (13,000-90,000 GPD) of municipal wastewater. Aspiral L3 model: Treats up to 300 m3/d of raw municipal wastewater Plug-and-play solution equipped with all internal air and wastewater piping 40% of container volume is aerated by fine bubble diffusers for residual BOD removal Arrives fully equipped and checked for fast installation and startup.

Treats up to 115 m3/d of raw municipal wastewater. Includes integral clarifier and pretreatment screen. Arrives fully equipped and checked for fast installation and startup.

Aspiral is a smart wastewater treatment solution that packages Fluence innovative MABR technology in standard shipping containers. This modular solution reduces energy usage for aeration by up to 90% compared to conventional methods. Aspiral S1 treats up to 20-25 m3/d of raw municipal wastewater, it includes integral clarifier and pretreatment screen and arrives fully equipped and checked for fast installation and startup.
