G&D Chillers, Inc. products

G&D's GD – 1.5H Nano Chill is a versatile mobile glycol chiller, initially designed for nano breweries and boutique wineries requiring precise temperature control. Its robust construction employs a powder-coated steel frame and stainless steel paneling for durability. The chiller is powered by a 1.5 HP scroll compressor and features an oversized 12-gallon reservoir. Enhanced mobility is achieved with heavy-duty locking casters. Key features include a complete refrigeration circuit, high-efficiency heat exchanger, and a glycol pump. It is built with an insulated stainless steel glycol reservoir, all copper piping, and a comprehensive control panel with safety mechanisms like pressure controls, freeze stat, and high-temperature alarms. The chiller also supports remote monitoring for a year, and its design ensures efficient maintenance with louvered access panels. It is designed for single-stage, digital temperature control and tested for reliability, making it suitable for diverse process cooling applications.

The innovative Multi Stage large chiller package provides all of the efficiency that comes with chillers outfitted with multiple compressors. Capacities ranging from 10 HP to 27 HP are sure to meet even the most chilling of demands. Every circuit is wired separately, giving each compressor equal run time over the life of the large chiller. These are designed to run on an as needed basis, which is ideal for applications with varying load requirements. The redundancy of multi-stage refrigeration circuits ensures that your process and production will never stop.

Ideal for high volume operations, each Vertical Air Chiller contains multiple semi-hermetic reciprocating compressors with capacity unloading. The GD-30H-2C is built with two 15 HP compressors partnered with oversized air-cooled condensers to maximize efficiency and cooling capacity. Vertical Air Chillers are complete package and turnkey units, with oversized stainless steel reservoirs, process and chiller pumps, compressors, and condensers. G&D Chillers will help engineer the optimum solution right down to the placement and commissioning of your unit at your facility.

The Elite 290 Microseries is a compact propane chiller specifically engineered for applications demanding efficient cooling in limited spaces and under extreme ambient conditions. Utilizing the advanced R290 refrigerant, the chiller offers a sustainable cooling solution with vertical hot air discharge and ultra-efficient variable-speed fans to enhance precision and noise reduction. The series is future-proof, aligned with environmental sustainability goals by evading restrictions related to HFC phase-out initiatives. This positions the Elite 290 not only as an environmentally friendly option due to its near-zero global warming potential (GWP) but also as a cost-effective choice due to its high efficiency and reduced CO2 emissions. Ideal for various sectors, the Elite 290 reflects the industry`s shift towards natural refrigerants and improved technological implementations to minimize ecological impact over its lifecycle.

The GD – 3T-1HA Micro Scroll Chillers are engineered for precision and efficiency, catering to medium to high-temperature applications across a variety of industries including distilleries, solvent recovery, HVAC, and more. Utilizing advanced scroll compressors, these chillers provide streamlined energy use and are equipped with a complete refrigeration circuit. Their design features include a microchannel air-cooled condenser, glycol pump, fluid bypass valve, and all-insulated copper piping, ensuring efficient thermal exchange and easy maintenance. Built with a powder-coated steel frame and aluminum housing, they host an insulated stainless steel glycol reservoir for optimal performance. A microprocessor controller allows for sophisticated communication capabilities, further supported by an ETL (UL508) listed control panel that consolidates electrical connections and integrates safety features. Additional elements include brass ball valves for glycol connections and strategically placed louvered access panels for simplified servicing.
