General Oceanics Inc. products

Level wind option, hydraulic level wind option, hydraulic.

WINCH, TOW Includes Towreel, Hydraulically operatation DRUM DIMENSIONS 20" DIA, FLANGE 34", WIDTH 18" Capacity 2500M 1/4" cable 230/460VAC, 3PHASE, 50-60HZ 10 hp, Universal Motor User selectable VAC 1200 lbs bare drum pull @ 200 FPM Winch may vary depending on length and Diameter of cable.

The CSW-7 is an electric winch designed for use in oceanographic and geophysical research. This model is capable of lifting and lowering most small instrumentation payloads, while remaining light enough for four people to transport. It has a drum capacity of 1000 m of 0.25` cable. A slip ring adapter can be added to accommodate Mercotac slip rings or Klein sonar (modified Focal Technologies 180) slip rings. For Focal Technologies Model 180 fluid slip rings, please refer to the CSW-8 winch.

WINCH, ELECTRIC PORTABLE 45-100KG The CSW-6 has proven to be a versatile winch which may be used in almost any application. This winch comes as a complete package, including a range of standard features only available as options on our other winches. Typical uses: side scan sonar, water sampling, towed bodies, environmental and pipe line monitoring, coring, subsea video, CTD profiling

Includes towreel, w58"x l58"xh58" drum dimensions 20" dia, flange 46", width 24" 5000m .316 cable 460vac, 3phase, 50-60hz .40 hp, 4400 lbs bare drum pull @ 200 fpm winch may vary depending on the length and diameter of the cable.

Portable Winch A.G.O.`s compact winches are designed to be easily portable and are ideal for light loads such as drop cameras, lightweight CTD profiling systems and line management duties.

Tow winch dimensions: width 32 inches depth 28 inches height 28 inches drum diameter 12 inches flange diameter 20 inches drum width 6 inches capacity:200 meters of .187.

Low-cost simplified winch for lightweight applications A.G.O.`s PID winches are designed specifically for borehole / drill hole and logging applications such as geophysics surveys and mining exploration. The reels are removable and the winch can be disassembled and reassembled easily in the field.

WINCH, TOW Electro-Hydralic Includes Towreel, Hydraulically operatation Width 62" Length 50" Height 50" DRUM DIMENSIONS 20" DIA, FLANGE 38", WIDTH 24" Capacity 5000M .255 Dia CABLE 230/460VAC, 3PHASE, 50/60HZ 20hp, 3200 lbs bare drum pull @ 150 FPM Winch may vary depending on length and diameter of the cable.
