GLOBAL TANK LEASING products

Capacity: 6500 to 7000 U.S. gallons (nominal) Suspension: Leaf Spring Lighting: DOT Lighting and reflective tape Outlet Valve: 3” SS QRB Hydrolet valve with 90 degree threaded outlet Construction: Straight Round and Double Conical- Stainless Steel Suspension: Leaf Spring Insulation: Insulated and Non-Insulated tanks Manhole: 20” diameter full opening 6 lug with gasket in cover Vents: 4” girard threaded pressure relief vent, 25 PSI MAWP, rated at a test pressure of 45PSI, complete with a Teflon encapsulated o-ring. Cleanouts: (2) 3” Threaded nozzles in tank shell on top centerline, locate max. 6” from head seams with solid caps

Capacity: 17,500 – 26,000 liters / 5,300 – 6,600 gallons Type: IMO-1, IM-101, DOT 407-412 Hazardous materials tank Tare Weights: Up to 7,400 lbs / 3,000 – 3,350 kg Construction: 316 Stainless steel barrel Thickness: Barrell @4.5MM, teak heads @5.5MM Insulation Urethane foam 2” , Rock Wool 2” Working Pressure: 3 bar- 43.5 psi 4 bar-58 psi Maximum Loading Temp 240o F – 300o F Dimensions: Outer - 20’ x 8’ x 8’-6” Interior 18’-10” x 7’-8” x 7’-9” Other: Bottom outlet equipped with 3” male Kamloc Tanks meet DOT, FRA, AAR, and CTS specifications

Capacity: 500 barrels, 21,000 U.S. gallons (nominal) Suspension: 25,000 lb. axles with automatic slack adjusters, top mounted 30 service chambers, outboard drums 11 x 24.5 Steel belted Mud flaps Lighting: LED lighting Modular wiring harness with snap connectors Sealed conduit/junction box system used throughout DOT reflective safety tape Mechanical Piping: One (1) 8" Pipe Manifold: One (1) 8" butterfly valve, two (2) 8" hammer lock universal hose couplings with caps, three (3) 4" internally threaded hose connections with caps 6” Sch 40 pipe; flanged with butterfly valve, with 6 jets 3” to 1 ½” One (1) 4" Fill Line: One (1) 4" external threaded fitting with cap One (1) Drain Line: One (1) 4" flange mount butterfly valve and One (1) 4" internally threaded hose connection Manways: Two (2) 20" manways sealed with six (6) grease fitting locking lugs (each) One (1) on front and one (1) on right side Roof Hatches Three (3)

Length: 20’ Carries one 20’ ISO Container Tank 40’ Carries two 20’ ISO Container Tanks Overall Chassis length 32’ 6” or 40’- 6” Axle: Tandem or Spread Axle Crank Handle: Curb side handle Lights: DOT approved lights and reflective tape Weight: Approximately 11,200 lbs +2% GVWR 65,000 lb Rims/Wheels 8.25 x 22.5 hub Brakes: Standard
