Redoma Recycling AB products

Thunderhawk A: Very compact and economical turn-key plant. Suitable for small companies wanting to earn money from their scrap cable quickly, but without big investments in machinery. Manually fed. Can be extended as your business grows. Thunderhawk B: Extended with a rough chopper increasing the capacity. Low personnel requirements and high degree of automation. Efficient and profitable cable recycling. It can even process light-armoured cable. Both Thunderhawk A and B are PLC operated and can process copper as well as aluminium cable. Thunderhawk - it is small, but big in performance.

POWERKAT A: Modular cable recycling plant. Suit­able for companies with a smaller amount of cable. Manually fed. Can easily be extended to a POWERKAT B. POWERKAT B: Extended with a 45 kW Rough Chopper, a Buffer Silo between Rough Chopper and Granulator increasing overall capacity and ensuring efficient separation. Suitable for forklift or crane feeding. POWERKAT C: Simplified version of PC B equipped with 37 kW Rough Chopper. No buffer silo between Rough Chopper and Granulator. Suitable for forklift or crane feeding.

FIREFOX: Highly automated and efficient cable plant made for tough conditions. Equipped with 45 kW Rough Chopper. Can be fed either with a forklift truck with tilting bin, belt conveyor or a crane with cactus grab. Equipped with intermediate storage bin with proportioning feeding and an efficient dedusting system. FIREFOX Turbo: Biggest cable recycling plant in REDOMA`s product range. Powerful, highly efficient and built for tough conditions. The Turbo version is using a 2 x 45 kW Twin Granulator and a strong 90 kW Rough Chopper increasing the capacity up to 1700 kg/h.

Modular cable recycling plant with an excellent price/performance ratio made for tough conditions with low investment costs at an overall low cost of ownership. The Powercat A (PC A) is a compact turn-key cable recycling plant and has typically a capacity of up to 550 kg/h for cable with a Cu content of 50% (capacity depending on type of cable). The PC A can easily be extended into a Powercat B or C by adding a rough chopper, increasing the capacity to approx. 800 kg/h.

Modular cable recycling plant with an excellent price/performance ratio made for tough conditions with low investment costs at an overall low cost of ownership. The Powercat B (PC B) has typically a capacity of up to 800 kg/h for cable with a Cu content of 50% (capacity depending on type of cable). It includes a 45 kW Rough Chopper equipped with hard metal knives that can process all types of dry cable up to diameter 120 mm with a length up to 1000 mm (containing steel up to diameter 2 mm).

A cable recycling plant with an excellent price/performance ratio made for tough conditions with low investment costs at an overall low cost of ownership. The Powercat C (PC C) has typically a capacity of up to 750 kg/h for cable with a Cu content of 50% (capacity depending on type of cable). It includes a 37 kW Rough Chopper equipped with hard metal knives that can process all types of dry cable up to diameter 100 mm with a length up to 800 mm (containing steel up to diameter 2 mm).

Highly automated and efficient cable plant made for tough conditions. Equipped with 45 kW Rough Chopper. Can be fed either with a forklift truck with tilting bin, belt conveyor or a crane with cactus grab. Equipped with intermediate storage bin with proportioning feeding and an efficient dedusting system.

Biggest cable recycling plant in REDOMA`s product range. Powerful, highly efficient and built for tough conditions. The Turbo version is using a 2 x 45 kW Twin Granulator and a strong 90 kW Rough Chopper increasing the capacity up to 1700 kg/h.

The Multi Purpose Rough Choppers of REDOMA are mainly intended for shredding of cables but can also be used for other materials, such as wood, plastics, cartons etc.

Motor for rotor: 18.5. Motor for hydraulic unit: 2.2. Motor for screw conveyor: 1.1. Rotor length: 680. Rotor diameter: 310. Rotor knives: 44. Fixed knives - lower: 2. Fixed knives - upper: -. Hopper volume: 1.0. Hopper opening: 1400x1290. Overall length: 2150. Overall width: 1510. Overall height: 2255. Weight, approx.: 1500. Max. cable diameter: 80. Max. capacity (*): 400. Max. capacity (**): 750. Installed in Redoma plant: Thunderhawk B.
