Sandvik Mining and Construction B.V products

Roller brackets are designed to mount rollers of a flat conveyor, belt conveyors return side and belt feeder.

Sandvik manufactures HM300 conveyor frames for belt widths from 400 mm up to 2000 mm (16" to 88") to suit HM100 rollers. Sandvik idlers and frames are designed to maintain an optimum conveyor belt profile which in turn promotes low rolling resistance, excellent belt support, good belt guidance and long belt life. Manufactured with high-grade steel, all Sandvik frames provide minimal gaps between rollers and are designed to counteract material build-up. Jig-welded for high precision, they have great structural integrity and optimal weight-to-load capacity ratios.

Sandvik tracking device automatically trains the belt and makes fast corrections in case the belt starts moving sideways - regardless if the reason is misalignment of roller frames, dirty belt or loading to one side of the belt etc.

Tracking of lower belt has an important effect on aligning conveyor belt. Hot-galvanized construction of the tracker gives good protection against corrosion.
