31 products found
ZH Seapration products
ZhongHan - Shale Shaker for Mud Recycling System
The Shale Shaker is used for the first-level solids control equipment of the drilling mud purification system. It adopts an imported excitation motor and is suitable for single, double or triple oil drilling fluid purification. At the same time, Shale Shaker can also be used for the mud cleaner. For underflow vibrating screen. Shale Shaker has high vibration intensity, large screening area, adjustable screen box angle, compact structure, and excellent performance. Shale Shaker is widely used in petroleum drilling, trenchless horizontal directional crossing, coalbed methane drilling, gas Drilling, river silt environmental protection and other mud purification treatment fields. The Shale Shaker is the first-class solids control equipment in the drilling mud solids control system, which handles the mud solid phase particles above 74μm from the bottom of the well. If you are interested in our equipments, please visit our web: www.zhseparation.com, send us email: sales@zhseparation.com
ZhongHan - Shale Shaker Screen
The screen is woven with metal wire or fiber wire, with an aperture of 0.15~1mm. It can remove and recover different types and small suspended solids, and the screen separation has the advantages of simplicity, high efficiency, and low operating cost. Generally used for small-scale wastewater treatment. Mesh of Screen from API20 mesh to API 400 Mesh. Including: composite screens, iron frame screens, wave screens, flat screens, polyurethane screens, stainless steel slit screens, etc. Model of Replancement Shaker Screen Replancement Shaker Screens Derrick 500, Derrick 2000, Derrick600, Derrick Hyper Pool. Replancement Shaker Screens MI-SWACO ALS, MI-SWACO Mongoose, MI-SWACO MD-3,BEM-3,BEM-6 Replancement Shaker Screens NOV Brandt King Cobra, NOV Brandt Venom, NOV Brandt VSM300, VSM100 If you are interested in our equipments, please visit our web: www.zhseparation.com, send us email: sales@zhseparation.com
ZhongHan - Decanter Centrifuge for Drilling Mud Separation
Decanter centrifuge for separation of detrital material of drilling mud is widely used in solid control system and waste management system for drilling mud to separate the solids phase of mud, remove harmful fine drill solids such as debris, etc. in the mud fluid, or recover weighting materials such as barite etc. so as to reduce the cost of mud fluid.. Two Phase Separation Decanter Centrifuge: Separate Solids and Liquid Three Phase Separation Decanter Centrifuge: Separate Solids phase, Liquid phase and oil. If you are interested in our equipments, please visit our web: www.zhseparation.com, send us email: sales@zhseparation.com
ZhongHan - Pneumatic Vacuum Pump
Pneumatic Vacuum Pump, also called solid transfer pump or drill cuttings transfer pump, is a pneumatic vacuum transfer pump with high load and strong suction. It is a kind of vacuum pump that forms a vacuum through pneumatics for suction, and then converts to a positive pressure for material discharge. It can pump various materials such as solid, powder, liquid and solid-liquid mixture. Its unique structural design and no rotating parts in the cavity enable it to work in the most difficult environment with low maintenance rate. It can transport materials with a solid phase of more than 80% and high specific gravity materials at high speed. It has the following characteristics: the high-efficiency Venturi device can produce up to 25 inches of HG (Hg) under strong airflow, which is equivalent to 85Kpa vacuum to suck the material, and there is almost no wear parts. If you are interested in our equipments, please visit our web: www.zhseparation.com, send us email: sales@zhseparation.com
ZhongHan - Vertical Cuttings Dryer for Drilling Waste Management
Vertical Cuttings Dryer is a single-stage continuous working vertical scraper discharge drying centrifuge, also called vertical drying centrifuge. Oilfield drilling waste treatment is one of the important equipment for the non-ground treatment of mud, which helps to solve the problem of separation and drying of drilling waste in the current oil-based mud environment and water-based mud environment. It is the need for mud not to meet the environmental protection requirements. The speed can reach 900RPM, which can form a separation factor of 420G and effectively separate the liquid in the drill cuttings. The discharge scraper is made of cemented carbide material and has a long service life. Each replaceable optional component has passed the dynamic balance test, and the balance of the whole machine after the replacement of the component. Independent oil circuit cooling system, equipped with a scientific oil tank cooling system, is required for use in high temperature environments.
ZhongHan - Centrifugal Pump for Drilling Mud
SB series Centrifugal Pump is a newly developed supporting pump for petroleum mine drilling solids control equipment. It adopts an axial suction structure, and the flow parts are all wear-resistant cast iron; it is suitable for transporting corrosive drilling fluid with suspended particles or other similar work. Condition of the liquid medium. The parameter design of the Centrifugal Pump fully considers that the supporting solids control equipment can work under the best working conditions. Its main features are strong interchangeability of parts, less leakage of shaft seal, reliable work, long service life, and convenient maintenance. If you are interested in our equipments, please visit our web: www.zhseparation.com, send us email: sales@zhseparation.com
ZhongHan - Mud Cleaner for Mud Recycling System
The mud cleaner is also called the integrated desander and desander. The mud cleaner is a three- and four-stage solids control equipment. Therefore, the mud cleaner plays a connecting role in the entire drilling fluid solids control system, and provides a guarantee for the better and more efficient operation of the centrifuge. The mud cleaner can be used in oil drilling, trenchless, shield tunneling and other fields and industries for mud treatment. The cleaner is easy to operate and maintain, and the vulnerable parts are interchangeable with international brands. Use ANSYS finite element analysis to optimize the structure design. Adopt American Martin, Oli brand excitation motor. International brands such as Siemens, Schneider, ABB, etc. are used for the selection of electrical components. If you are interested in our equipments, please visit our web: www.zhseparation.com, send us email: sales@zhseparation.com
ZhongHan - Horizontal Mud Agitator and Vertical Mud Agitator for Mud Tank
Horizontal Mud Agitator and Vertical Mud Agitator is a part of solid control system, which is mainly used in agitating and blending drilling fluid so as to control the deposition of solid particles in the recycling system and keep the mud property of circulation stable and mixture uniform. Horizontal Mud Agitator and Vertical Mud Agitator is an efficient mud mixing machine. Through customized size and configuration, it can meet the requirements of different types of mud tanks. The agitator is installed on the top of the mud tank, and all layers of impellers sink into the mud. The stirring shaft and the motor are connected through a coupling. The selection of agitator should consider tank size, depth, and mud parameters. If you are interested in our equipments, please visit our web: www.zhseparation.com, send us email: sales@zhseparation.com
ZhongHan - Drilling Waste Management System
Why we need Drilling Waste Management System Reduction: Reduce The Amount Of Drilling Sludge Use: Re-Use Valuable Drilling Fluids Regenerate: Regenerate Oil Or Water For Recycling Restoration: Restore Waste That Pollutes The Environment To Become Waste That Won't Pollute The Environment. Sort of Drilling Waste Management System Drilling Waste Management System for water-basted drilling mud. Drilling Waste Management System for oil- basted drilling mud. Flocculation System for the liquid from the drilling waste management system. If you are interested in our equipments, please visit our web: www.zhseparation.com, send us email: sales@zhseparation.com
