BULLY - Model C140 -Jacket Cooled Submersible Drainage Pump
For irrigation and drainage in clear or drainage water. Cellar drainage, pumping water from sumps, pits and rooms. Also suitable for pumping discharge from hand basins, showers and washing machines, for flood relief and water removal from water courses or reservoirs.
10 m connecting cable permits the mobile outdoor use and an immersion depth of 7 m. Cooling jacket ensures optimum motor cooling even during sip operation. Automatic air bleed valve with additional venting screw. Detachable suction sieve for low suction of residual water. Automatic flushing if required.
DIN EN 12050-2: Conformity and design approved and controlled by LGA. Installation: Permanent or transportable. Model with float switch control for automatic pump operation, depending on liquid level in the sump. Float switch fixation for continuous operation mode. Pumped liquid: Clear water or drainage water containing soft solids up to 10 mm spherical clearance. Max. liquid temperature: 35°C, short term up to 60°C. Operation: Permanent.
Fully submersible drainage pump unit consisting of:
Pump: Single stage centrifugal pump with cooling jacket and horizontal discharge G VAM. Impeller: Open multi-channel impeller, spherical clearance 10 mm. Motor: Fully submersible, pressure tight electric motor. Insulation class F. Motor protection IP 68. Thermal sensors imbedded in the motor winding. Rotor shaft from stainless steel with ceramic coated sealing surface, pre-lubricated bearings. Seals: 3 Triple lip-seal combination
