Armatec - Model N and NF -Cavity Pump

• compact design,
• low weight,
• short overall length,
• high performance
• flexible numbers and positions of suction nozzles
• different materials

• 1.5 – 22 kW

NF – version: Flange-mounting gearmotors

N – version: Foot-mounting gearmotor and mounted on a baseframe

The applications for cavity pumps are low and high viscosity fluids. This fluids could be also mixed with fibres or abrassive slurries and gases. Their field of use ranges extends up to pastes, which could be pressed through pipes.

• 3 – 24 bar
• 4 – 360 m³/h

• Rotor: hollow or full rotors in steel / stainless steel (ss304/ss316) and hardened  – depending on the application

• Different joints

• Oil-chamber housing with mechanical seals

• Stators in different elastomers (NBR, EPDM, PTFE, PU, CSM) – also available in adjustable versions for a longer service life

• Installation and maintenance without special tools

• raw materials which are reproductive like corn, grass
• substrates for Biogas production, food residues, vegetable waste
• liquid manure
• waste water
• emulsion
• sludge, slurry
• cut up fruits
• colours and lacquers …
