ClydeUnion - Model Aquaglide -Single and Two Stage Pump
FromSPXFLOW
The Aquaglide range of high efficiency large end suction pumps has been developed for high capacity water pumping applications. A range of material and coating options is available catering for non-corrosive and corrosive applications including seawater. The Aquaglide range covers duties from 250 m3/hr to 10,000 m3/hr. Larger duties are covered by our engineered range (please contact our marketing department for further details). For lower flow duties please refer to the Isoglide range of medium end suction pumps.
Most popular related searches
suction pump
utility water
water pump
water distribution
petrochemical industry water
industrial water
water utility industry
petrochemical industry water treatment
metal industry water
water supply
- Capacity: up to 10,000 m3/hr / 44,000 gpm
- Delivery head: up to 120 m / 400 feet
- Temperature: up to 80 oC / 180 oF
- Speeds: up to 1,500 rpm
- Flange drilling: BS or ANSI
- Irrigation
- De-watering
- Power/cogeneration
- Desalination
- Mining
- Metal manufacturing
- Petrochemical
- General industrial utility
- Water distribution / supply / treatment
- Low energy costs
- Hydraulic design provides high efficiency, low npsh and stable characteristics
- Optimum seal performance
- Single, double and cartridge options. Packed gland available on request
- Extended bearing life
- Grease lubricated. Oil lubricated as a non-standard option
- Ease of maintenance
- Back pull out design allows full access without disturbing site pipe work or driver
- Low power consumption
- Shrouded impeller design provides high efficiency and low hydraulic thrust
- Wear options
- Casing wear rings fitted as standard, impeller wear ring option available
- Modular design
- Minimises spares holding of back pull out components
- Centre line discharge
- Self venting casing design prevents air entrapment in the top of the casing
- Simplified build procedures
- Spigot design facilitates self setting axial clearance
