The development of the 3D Principle was based on analyzing every drying factor and how it would effectively dry each individual resin pellet. The advantages include:
- Completely isolates the material between the interior and exterior of the hopper by creating a temperature barrier for thermal decoupling.
- An integrated ring-jet system ensures consistent temperature control and process air distribution in the hopper.
- Sophisticated, adjustable sensors inside the material hopper ensure exact process monitoring and control of compressed airflow so every resin pellet is uniformly dehumidified.
- A compressed air module, with display and control functions efficiently controls the material during the entire drying process. The compressed air module is attached to the material hopper using a centralized compressed air coupling.
- Choose between two compressed air control modes, normal and expert. The expert mode is ideal for drying difficult materials like TPE, high temperature thermoplastics like PEEK, or filled materials.
- The large, removable swiveling display is readable up to 50 ft., providing the operator with an optimal view so errors are minimized.
- Can be equipped with infinitely variable, adjustable hopper sensors that are integrated into the control system of the dryer to reliably ensure exact process monitoring.
- High-quality stainless steel components and PTFE parts make the 3DX dryer perfect for clean-room applications.
- A hopper extension allows for quick, flexible material hopper changes to adjust the volume in the hopper to the production.
- Simple construction enables easy accessibility and maintenance.
