Concept - Model ILDD-054 - In-Line Desiccant Air Dryer
From In-Line Desiccant Dryer - Air Tool Dryer
The compressed air flow through the bottom of the dryer and distributed uniformly and passed through the desiccant bed. The moisture is drained at the bottom either with manual drain w automatic drain valve (optional). The desiccant adsorbs moisture, the color of desiccant changes from blue to Pink/White. The color of desiccant will change gradually from blue to white as desiccant gets saturated. The full desiccant bed will reach to its maximum drying capacity and must be either changed or charged/ regenerated.
-
Most popular related searches
Products Details
Rogonoration Process :
Regeneration is accomplished by healing the desiccant to a temperature of 275 deg F In drying oven for 2-3 hrs or till (he desiccant returns lo its blue color.
INSTALLATION :-
The installation can be done IN-LINE with flexible PU tube and connectors provided with the unit. Please
see below the installation diagram.
