Bea Technologies - Model XAM 200 - XAM 200 EC -Differential Pressure Gauge
XAM-200 is designed to measure the differential pressure between inlet and outlet of AIR-VIP and VACUUM VIP filters. No pressure behind the window. Potential-free contact for model XAM 200 EC. The fluid doesn’t enter in contact with the window. Easy readable from both sides. Indoor installation.
The measure of differential pressure allows to identify when the change out of the filter element is suitable and convenient. The pressure gauge has on both side a scale in two colors in the range from 0 to 0,7 bar.
The indicator on the green zone means that filter is using the right amount of energy. The indicator on red zone means that the filter is absorbing too much energy therefore the filter element should be substituted.
Some hints, as no pressure behind the window and special membrane gaskets, provides XAM 200 a great safety and accuracy.
XAM-200-EC has all the characteristics of XAM-200, but is equipped with potential-free contact for remote monitoring of the differential pressure gauge.
XAM-200 differential pressure gauge is interchangeable with XAM-100 model.
The instrument is suitable for indoor installations.
