- Horizontal In-line Disc Pumps

0

Discflo’s line of horizontal, end-suction Disc Pumps use the unique Discpac technology to provide a superior alternative to centrifugal and PC pumps in tough applications. Disc pumps have no close tolerances and deliver laminar, pulsation-free flow. They excel at handling abrasive, high-solids (up to 90%) and/or viscous fluids. They can also pump air or gas entrained fluids, up to 80% by volume, and large or stringy solids, without clogging. The Disc Pump’s unique non-impingement Discpac ‘impeller’ prevents degradation, emulsification and damage to delicate and shear sensitive products.

Configurations Available

Horizontal Disc Pump configurations include: Direct-coupled in-line pumps, with channel or formed  ases; close-coupled pumps; frame-mounted pumps; side-by-side pumps, over-under pumps and self-priming models. Impeller sizes vary from 8-inch to 20-inch (metric sizes from 203mm to 508mm).

We specialize in stainless steel, CD4, Maxalloy, Hastalloy and other exotic metal and non-metallic construction materials. Our engineering specialists can advise you on the best configuration, model and metallurgy to suit your particular application.
