ABB - Model RHD1250 / RHD2500 (Contrac) -Electrical Electrical Rotary Actuator
Compact actuator for the operation of final control elements with rotary movement. For continuous positioning, rated torque 1250 / 2500 Nm (1000 / 1900 lbf-ft). The actuator thrust rod transfers the force directly to the final control element.
Most popular related searches
- Process optimization thanks to maximum control precision
- Maintenance-free up to 10 years
- Electrical actuator for continuous positioning, three-point position control, or bus control
- Stallproof without the need for position- or torque-dependent shut-off
- Adjustable mechanical limit stops for defined operating range
- Handwheel for emergency operation
- Signal and power input only via separate, microprocessor-controlled electronic unit
- Rated speed
- RHD1250-12,0 – 12 to 900 s/90°
- RHD2500-10,0 – 10 to 900 s/90°
- RHD2500-25,0 – 25 to 900 s/90°
- Operating angle – min 35° / max. 300°
