Linn - Model F Series -Gear Flange Pumps with Free Shaft End
FromLinn-Pumpen GmbH
Self-priming external gear pumps with mounting flange, compact pump housing in cast iron. Standard suction and pressure port: pipe thread (opposite 180°), for type F5.. SAE-flange optionally. mounting position variable
Most popular related searches
gear pump
flanged pump
self-priming pump
external gear pump
gear flange pump
dosing pump
mechanical dosing pump
pump test
pressure pipe
detergent testing
Examples of liquids suitable for transport
- Hydraulic oil, gear oil, engine oil, mineral oils, synthetic oils, emulsions and pastes without abrasives. For lubricating liquids.
Operating conditions
- Liquid temperature: -20°C to +60°C (NBR)
- Ambient temperature from -20°C up to +40°C
- operating pressure: max. 100 bar
- others on request
Drives
- For example: hydraulic motor, electric motor
- drives without axial / radial forces on the drive shaft
The self-priming gear pumps are used in industrial applications as an oilpump, lubrication-pump and capacity-pump for oily and lubricating liquids.
oilpumps in bearing systems
- mechanical engineering
- dosing pumps
- lubrication pumps in testing applications
- detergent dosing pump
