FST - Model Micro Series -High Performace BET Surface Area and Pore Size Analyzer
The Micro Series can accurately produce surface area and pore size results of powder materials. According to the different test functions, this series of instruments are divided into three types, there are A, B, and C, the C type is configured with 1 torr or 0.1 torr high-sensitive pressure sensors and turbo molecular pump with ultimate pressure of 10-8 Pa, it can effectively take microporous analysis of microporous materials such as molecular sieve, catalyst, activated carbon, and other microporous materials.
Test Module
Internal temperature of test module can be controlled through Real-time monitoring, ensuring accuracy of adsorption detection.
Saturated Vapor Pressure P0
Using independent P0 pressure sensor for P0 value by inching test, guarantees the reliability of experimental data. Atmospheric pressure input method to determine P0 also be selected.
Vacuum System
It’s a multi-channel, adjustable, and parallel vacuum system. Vacuum degree of this system can be controlled in segments.
This design prevents the sample from being pumped into analyzer. Meanwhile, a delicate part was designed for ensuring cleanliness of vacuum system, minimizing dust pollution.
Sample Preparation System
In addition to two pretreatment stations, the other two analysis stations can be used in preparing samples. There is no interference between pretreatment stations and analysis stations. Degas temperature can be set individually and controlled from ambient to 400 ?.
Micropore Distribution
Accurately apply the HK method, SF method and other micropore analysis model, the aperture deviation of micropore is less than 0.02 nm.
Pressure Sensor
Micro 200C with 1torr (selectable 0.1torr) makes the partial pressure of P/P0 up to 10-7 - 10-8 (N2/77K) in the physical adsorption analysis.
Cold Free Space
Cold free space can be corrected by Helium automatically, ensuring accuracy of test results.
This calibration method is suitable for testing of any powder or particle material.
Control of Liquid Nitrogen level
Using High volume (3L) Dewar flasks and working with the seal cover assure a constant thermal profile along the length of sample tubes and P0 tubes throughout testing process.
Turbo Molecular Pump
Molecular pump is a standard configuration part on the Micro 200C. The ultimate pressure is up to 10-8 Pa, providing a strong support for micropore analysis in the ultra-low pressure. The smallest micro-pore diameter can be tested is 0.35
Control and Analysis Software
Micro Software is intelligent software in operation control, data acquisition, calculation and analysis and report generation on the Windows platform. This software can communicate with the host through the LAN port and remotely control many instruments at the same time. Software adopts a unique intake control method, the pressure in adsorption and desorption process is optimally set in six- stage; this flexible design is helpful for improving test efficiency.
Clear tabular reports include:
- Adsorption and desorption isotherms
- Single-/Multipoint BET surface area
- Langmuir surface area
- STSA-surface area
- pore size distribution according to BJH
- t-plot
- Dubinin-Radushkevich
- Horvath-Kawazoe
- Saito-Foley
