ResinTech - Model IT-5 -Inert Media Floating Support Bed for Use in Packed Beds
ResinTech IT-1 is an inert low density support media for packed beds. IT-5 is significantly less dense than water and is rectangular in shape. IT-5 is intended to float above the active resin in packed bed ion exchangers. ResinTech IT-5 acts as an upper support bed and prevents resin fines from clogging distributer screens. IT-5 is supplied in an inert form.
- Polymer Structure: Polypropylene
- Physical Form: Rectangular pieces
- Approximate Shipping Weight: 33 lbs./cu.ft.
- Screen Size Distribution: 8 to 16 (U.S. Mesh)
- Maximum Fines Content: 1 percent (less than 50 Mesh)
- Minimum Sphericity: 95 percent
- Uniformity Coefficient: 1.2 (Approximate)
- Resin Color: Clear white
Truly Inert
Not soluble in acids or bases, has high resistance to oxidation, contains no ion exchange functionality
High Void Space
Rectangular shape creates a large void space while maintaining excellent separation between the active resin layer and the upper distributer screens
Superior Physical Stability
Good physical integrity helps minimize breakage and fines formation
Controlled Granule Size
Large granules provide good physical strength and minimal fines provide low pressure loss
Support Layer for Packed Beds
ResinTech IT-5 is an inert floating support bed designed for use in packed bed demineralizers. The inert material fills the space between the top of the resin bed and the upper distributor/collector and minimizes the total freeboard. The inert media prevents resin fines from blocking the distributor screens and reduces pressure loss. The media also acts as a support bed to promote even liquid distribution and prevent channeling.
