HOMA - Model C 135 W -Jacket Cooled Submersible Drainage Pump
FromHOMA Pumps
The C 135 W pump is suitable for water circulation in garden ponds and cascades, irrigation, water transfer and drainage in clear or waste water. The water jacket cooled motor with the top discharge protects the motor against overheating even during sip operation.
Installation: Permanent or transportable. Pumped liquid: Clear or waste water containing soft solids with a diameter of max. 8 mm. Max. liquid temperature: 35°C, short term up to 60°C. Operation: Permanent.
Most popular related searches
submersible pump
submersible drainage pump
discharge protection
water disposal
submersible drainage
drainage pumping
domestic waste
water circulator
water containment
drainage pump
Fully submersible pump consisting of:
- Pump: Single stage submersible pump with vertical discharge BSP 1" M.
- Impeller: Vortex impeller, spherical clearance 8 mm, self-cleaning in case of blocked impeller by short-term reverse running of the motor.
- Motor: Canned wet-rotor, seal-less, rotor shaft lubricated by pumped liquid. Insulation class B. Motor protection IP 68.
- Shaft/bearing: Stainless steel-ceramic shaft, slide bearing.
- Cable: H05RN-F3G0,75
