K.H. Brinkmann - Model SBF125...1150 -Horizontal End-Suction Pump

SHARE

are centrifugal inline pumps with a compact design where the impeller is mounted onto the extended motor shaft. These pumps are not self-priming and must be gravity fed. The SBF125 pumps are equipped with double mechanical seal. The SBF550...1150 Pumps are equipped with a single mechanical seal. Upon request a second mechanical seal is available to allow for dry-running (-GD).

Most popular related searches
end suction pump
suction pump
end suction centrifugal pump
pump system
coolant fluid
inline pump
pressure gauge
centrifugal pumping
centrifugal pump
inline centrifugal pump

This pump series is designed for horizontal installations next to a tank and for pumping air entrained coolant fluids, such as water-soluble coolants (emulsions), as they occur in high speed machining applications, such as turning and milling. The SBF* pumps are equipped with the user-friendly 45 degree flange connection which allows for either vertical or horizontal pipe connection and the connection of a pressure gauge with G ¼.
*) SBF125...550 with SAE flange. For more information see lifting pumps features SFL/SBF within the technical information section.
