P&CT - Model MBR -Membrane Bioreactor
PACT compact MBR is state of the art pre-engineered sewage treatment system utilizing PACTs biological treatment expertise with submerged membrane technology, it contains the process elements of secondary, tertiary and advanced wastewater treatment in a single containerized package. The membrane separation process eliminates the conventional sedimentation tank and allows high volumetric loading resulting in a much smaller footprint.Most popular related searches
membrane bioreactor
submerged membrane system
membrane separation process
advanced wastewater treatment
sewage treatment system
biological treatment
TSS removal
sedimentation tank
advanced wastewater
BOD removal
PACT compact MBR can produce high quality effluent with high BOD removal (about 98%), complete nitrification and partial denitrification. It also achieves virtually complete TSS removal. Treated effluents have low turbidity values (<0.3 NTU) and SDI values (<3) which can be re-used for landscaping, flushing or feed to NANO or RO for higher purity water.
- Much Smaller space requirements
- Better solids removal (elimination of bulking)
- Disinfection
- Increased volumetric loading
- De-coupling of hydraulic and biomass retention time
- Production of less sludge due to high sludge age
- High SRT which allows the development of slow-growing microorganisms such as nitrifying bacteria and retention of high molecular weight organic compounds that can enhance the bio degradation process.
