Model FDH-1802 -Lubricating Oil Low Temperature Brookfield Viscosity Tester

FromChangsha Friend Experimental Analysis Instrument Co.,Ltd

SHARE

This instrument can measure the absolute viscosity of Newtonian liquid. Widely used in oils, paints, slurries, textiles, food, pharmaceuticals, adhesives, cosmetics and other production industries and research units. The instrument is accurate, fast, intuitive and simple, and has been selected by customers in various industries.

Most popular related searches

viscosity testing

hybrid stepper motor

temperature monitoring

viscosity meter

temperature probe

lubricant oil measurement

industrial viscometer

interface monitoring

research instrument

The Brookfield viscometer adopts LCD liquid crystal display. The buttons are clearly marked, programmed and easy to operate.
The Brookfield viscometer uses a 16-bit microcomputer processor as the core stepper motor with high subdivision drive and stable rotation speed. Accurate
Brookfield viscometer adopts program design, easy operation, alarm function, screen directly shows viscosity, speed, percent torque, rotor number
Brookfield viscometer temperature measurement range is -20 °C-100 °C, Wide temperature range detection.
The main control board and subdivision driver board of Brinell viscometer adopt patch technology. The circuit design adopts advanced microcomputer processor, and the structure layout is reasonable and compact. The full scale of the instrument and the linearity of each gear are all metered and corrected through the PC interface, and its metering performance and function reach the advanced level of the same type in China.

Measurement range: 1—2000,000 cp If it is lower than 20cp, it needs to be equipped with 0# rotor
Unit conversion: 1pa.s = 1000 mpa.s 1pa = 100mpa.s 1 mpa.s = 1 cp
Rotation Speed: 0.3, 0.6, 1.5, 3, 6, 12, 30, 60 Eight kinds of speed program control, automatic adjustment, imported motor
range display: automatically display the selected maximum viscosity value of the combination of rotor and speed
Scanning function: The machine can automatically prompt the appropriate rotor speed combination according to the viscosity value of the test sample.
Number of rotors: 4 types of rotors randomly arranged 1, 2, 3, 4
Peripheral interface: R232C communication interface, temperature One probe interface, one power socket,
measurement accuracy: ≤±2.0% (Newtonian liquid)
Reproducibility: 0.5%
Power supply: 110V-230V 50HZ/60HZ
