Model FDW-0871 -Portable Dissolved Oxygen Meter

FromChangsha Friend Experimental Analysis Instrument Co.,Ltd

SHARE

Fully watertight (IP67 waterproof rating), impact resistant instrument housing, and innovative dissolved oxygen electrode modules that can be replaced in the field. Dissolved oxygen and temperature can be measured simultaneously using YSI`s proven polarography technology and YSI`s global high-precision temperature model of thermistor technology. The new generation PE cover film provides faster reaction times and lower agitation dependence.

Most popular related searches

portable dissolved oxygen meter

dissolved oxygen electrode

portable dissolved oxygen

field dissolved oxygen

dissolved oxygen meter

dissolved oxygen monitoring

instrument housing

resistivity instrument

the United States YSI brand
dissolved oxygen (% air saturation):

measurement range 0 to 500%
resolution 0.1% or 1% air saturation (optional)
accuracy 0 to 200%: ± 2% of reading or 2 % air saturation, whichever is greater; 200 to 500%: ±6% of reading

Dissolved oxygen (mg/L):
Measurement range 0 to 50 mg/L
Resolution 0.01 or 0.1 mg/L (Can Optional)
Accuracy 0 to 20 mg/L: 0.3 mg/L or ±2% of reading, whichever is greater; 20 to 50 mg/L: ±6% of reading
Note: Instrument accuracy specifications are host and The sum of the probes

Working conditions Water body: fresh water, sea water or sewage; temperature: -5 to +45 °C
Dissolved oxygen reacts to 95% of the final value within 9 seconds
Salinity compensation 0 to 70 ppt
Waterproof specification IP67 waterproof rating
power supply 4 section 2 alkaline battery (25 ° C, more than 2000 hours)
cable is available in 3.7 meters, 7.5 meters, 15 meters and 30 meters to choose from
size 22.9 cm (length) × 11.9 cm (width)
weight 0.91 kg (with battery)
