Model GPE, GPM -Self Priming Centrifugal Pumps
FromHOMA Pumps
HOMA self priming centrifugal pumps are the ideal solution for many applications in house and garden. High performance, silent operation and low weight easy handling are the main advantages of these units. By installation of the automatic pump control HPS 2 (see HOMA accessory program) on the discharge of the electric motor driven pumps, the pumps are able to operate as fully automatic pressure booster units.
Pumped liquid: Clearwater. Max. liquid temperature: 35°C. Operation: Permanant (S1).
Most popular related searches
self-priming centrifugal pump
centrifugal pumping
centrifugal pump
self-priming pump
stainless steel pump
multistage centrifugal pump
centrifuge
impeller centrifugal pump
pump controller
jet pump
- Pump: GPE 60, GPE 71: Single stage jet pump with stainless steel pump housing and stainless steel impellers. GPE 105: Multistage centrifugal pump with stainless steel pump housing and noryl impellers.
- GPM 121: Single stage centrifugal pump, aluminium pump housing, cast iron impeller.
- Self priming centrifugal pumps wfth electric motor or petrol motor.
- Motor: Serie GPE with single phase electric motor, insulation class R motor protection IP 44. Voltage 230-240 V, 50 Hz. Speed 2900 ipm. On-Off swftch. Cable length 2 m. Type GPM 121 wfth two stroke engine.
- Shaft seal: Mechanical seal.
