IUT - Model MPS -Multi Point Sampler for Subsequently Continuous Monitoring
Our MPS (Multipointsampler) is designed for subsequently continuous monitoring of multiple measuring points. It’s designed to work as an integral part of a measuring system. It is used for online measurements. The sample pump, valves and sample lines are at ambient temperature. It is an ideal tool to measure components in ambient conditions from several measuring points.
Most popular related searches
gas sampling point
multipoint sampling
flow meter
gas analyzer
sampling pump
sampling valve
sample gas
gas sampling
gas point analyzer
metering pump
The design is based on blocks of 4 measurement channels each. You can combine this by up to 16 points per device. It is available in a wall mounted stainless steel case or 19″ rack system which includes all valves, a flow meter and two pumps. The function of the MPS is fully automatic and controlled by the internal software.
- Long-term-stability and reliability
- Solid-state electronics and few moving parts
- Low Maintenance Time - High Up Time
- Different enclosures possible
Description
- Multipoint Sampling System for Gas analyzers
- Sample Points chooseable between 4,8, 12 and 16 points per device
- Solid-state electronics and few moving parts
