Solgeo - Model MAS24 -Seismic Recorder
The high resolution integrated unit (24-bit sampling and dynamic 130 db) 3 or 6 channels (up to 6 rnonoaxial or 2 Triaxial accelerom-eters in version 6.SD.) can operate as a strong motion vibration acquisition unit or micro seismic recorder fulfilling international standards DIN45669 DIN4150-3-1 and UNI9916. Its characteristics make it suitable for monitoring of civil and industrial structures or for natural or anthropic seismic monitoring.
The high resolution allows the use of this instrument in micro seismic field or as a strong motion acquisition unit. Thanks to internal GPS receiver data are syncronized with an absolute time reference and then correlated with other remote stations. Software packages for configuration and communication, EDAXSOFT, and data processing and visualization, VIBROSOFT, are also supplied Signals are stored in an internal Compact Flash or directly on PC Remote downloading is provided by GSM-GPRS modem or Ethernet network. The unit, in addition to recording signal in case of event, storages of minimum and maximum values for all channels.
