BEL ValvesSubsea Check Valves

SHARE

BEL Valves’ Check Valve range supports client needs for a flexible approach to solutions where protection against backflow and pressure surges are concerned. The robust design of the Swing Check Valve is typically favoured to overcome these service conditions on large bore applications, whereas the Axial and Piston Check Valve products provide assurance where more compact design is demanded.

Most popular related searches
  • Pressure rating : ANSI 150 to 4,500 API 2,000 to 20,000 psi
  • Water depth : 4,500 m
  • Bore sizes : ½” to 42”
  • Material options : Carbon and low alloy steel, stainless steel, duplex, super duplex and super alloys
  • Typical standards : API 6A and ISO 10423, API 6D and ISO 14313
  • Piston, Swing and Axial Check
  • Various end connection options
  • Lock open
  • Non-return
  • Metal-to-metal sealing

Materials, specification and approvals.

All of our check valve designs are in accordance with the relevant industry codes and standards including ISO 13628, ISO 14723, API 6DSS, API 17D and API 6AVI.
