Synova - Model DCS 150 -Diamond Cutting System
FromSynova S.A.
The DCS 150 is Synova’s diamond cutting system for small and medium-sized natural and laboratory grown diamonds. The 3-axis machine allows sawing rough diamonds with a size of 2 grz. to 4 cts. and coring and slicing of CVD diamonds. Since no focal adjustment is required, a working distance and cutting depth of up to 30 millimeters is possible. Thus, a diamond can be cut in a single setting rather than from both sides, as it is the case with conventional lasers.
Most popular related searches
Materials:
Rough diamonds
Laboratory grown diamonds (CVD, HPHT)
Operations:
3-axis machine: Sawing, coring, slicing
- Easy
- No focus control necessary due to long working distance
- No blackening, no opening, no double sawing needed
- Very little post treatment required
- Profitable
- Minimal weight loss and low risk of breakage
- Fast cutting time and easy processing
- Diamond sawing in mass production
- Straight and Smooth
- Smooth cutting surfaces and sharp edges
- Cylindrical beam resulting in perfectly parallel kerfs (no V-shape)
- Virtually no heat impact thanks to the water jet cooling capability
